Scene 1 (0s)
Synchronization – Synchroscope Interpretation. Marine Engineering Function 2 Electrical, Electronic and Control Engineering.
Scene 2 (7s)
Exam Scenario. During synchronization, the synchroscope rotates rapidly clockwise. What does this indicate?.
Scene 3 (16s)
Choices. A. Incoming generator frequency is lower B. Incoming generator frequency is higher C. Voltage is too low D. Phase sequence is incorrect.
Scene 4 (27s)
Correct Answer. B. Incoming generator frequency is higher.
Scene 5 (34s)
Key Concept. Synchroscope shows frequency difference between incoming and running generator. Direction of rotation indicates whether incoming generator is faster or slower..
Scene 6 (45s)
Clockwise Rotation Meaning. Clockwise rotation = Incoming generator frequency is HIGHER than busbar frequency. The generator is running faster..
Scene 7 (54s)
Counterclockwise Rotation. Counterclockwise rotation = Incoming generator frequency is LOWER. The generator is running slower..
Scene 8 (1m 3s)
Speed vs Frequency. Generator frequency depends on speed: Higher speed → Higher frequency Lower speed → Lower frequency.
Scene 9 (1m 12s)
What To Do Onboard. If rotating clockwise (too fast): - Reduce prime mover speed If rotating counterclockwise (too slow): - Increase speed Goal: Stop needle at 12 o’clock before closing breaker.
Scene 10 (1m 23s)
Common Exam Trap. Clockwise = Faster Counterclockwise = Slower Do NOT confuse with voltage or phase sequence.
Scene 11 (1m 32s)
Quick Recall. Clockwise = FAST Counterclockwise = SLOW.
